Cyklop

Cyklop SF/SP 112 M┃Strapping Machines

Automatic Side Sealing Vertical Strapping Machine

The SF/SP 112 M is from Cyklop’s new Smart line. It can be equipped with either of Cyklop’s CFH-1 or CFL-2 strapping heads which use industry leading strapping technology, including multi-stage tensioning (max 1250 lbs) and is electronically controlled with 5.7” touch panel display. The SF model contains a permanently closed strap chute, while the SP model includes a pallet lance for through pallet strapping. It is designed to seamlessly integrate into any existing production lines and can be optimized further with movable or floating strapping heads.


  • Compact, minimal space required.
  • Easy access to all the mechanical components to facilitate service and maintenance.
  • High strap tension, up to 1250 lbs.
  • Modular adaptation to type and size of package.
  • CFH-1 or CFL-2 strapping head is maintenance-friendly.
  • Easy to integrate into existing conveyor lines. Adjustable height.
  • Fully electric, 3-ph. + N.
  • All machine functions are controlled electronically, with clear text display for operator guidance.
  • The bottom section of the strapping arch can be a standard under track style (XF) or a pallet lance for through pallet strapping (XP).
Machine Weight Determined by customer requirements
Machine Dimensions Determined by customer requirements
Max. load size
 47” W x 82” H
Min. load size 32” W x 18” H
Max. load weight limited to conveyor capacity
Power Requirements 400 V 3F N T -50 HZ 24 V DC 2.5 kW
Tension 1,250 lbs. (CFH -1) 500 lbs. (CFL-2)
Strap Size 9mm-19mm (3/8” – 3/4")
Strap Thickness 0.4mm-1.2mm (0.015” – 0.044”)
Strap Core Size 16”
Sealing Method Friction -weld
